Aluminum Parallel Connector

The aluminum parallel connector is a critical component used for creating secure and reliable connections between aluminum conductors, ACSR (Aluminum Conductor Steel Reinforced), and copper conductors. Designed for various dead end terminals, this connector ensures optimal performance in electrical systems.
The aluminum parallel connector is a reliable and efficient solution for connecting aluminum and copper conductors in various electrical applications. Its high-quality aluminum construction, compatibility with different conductor types, and crimping design ensure secure connections while minimizing resistance and temperature rise. With features that enhance durability and performance, this connector is essential for maintaining the integrity and efficiency of electrical systems.

Features & Advantages
Index & Specification
leave a message

Description Of Aluminium Parallel Connector

1.Material: Aluminium
2.Size: CPO 10-16/10-16~CPO 150-240/150-240
3.Type: Crimping type
4.For ACSR, aluminium and/or copper conductors in various dead end terminals.
5.No burr on the surface

Features
1.Increase the anode, reducing erosion
2.Current uniform distribution, low resistance.
3.Low temperature rise.

If you want to know us, please contact us!

We always adheres to the quality policy of "Innovation is infinity, to keep improving",adhering to the enterprise tenet of "Veracity,Customer regarded supreme".
- Company.
- E-mail*.
- Name*.
- Phone.
- Message*.

about us

Our Story

Xinchang TuAn Machinery Co., Ltd.Rooted in the past, facing the future?

Based on customer needs, connect the products and technologies required by customers with the scientific research capabilities of universities to achieve innovation based on customer needs.

TuAn is famous China Aluminum Parallel Connector manufacturers and Aluminum Parallel Connector factory, the company continuously strengthens cooperation with upstream and downstream enterprises, rapidly expands comprehensive service capabilities, and transforms from a single lightning protection enterprise to a comprehensive large-scale project supporting enterprise. After years of accumulation, TuAn has formed a stable customer base covering important fields such as petroleum and petrochemical, high-speed rail, and electric power.

Model	Hole 1 mm2	Hole 2 mm2	Size
Model	Hole 1 mm2	Hole 2 mm2	A	B	L
CPO 10-16/10-16	10-16	10-16	18	10.5	32
CPO 16-35/10-16	20-35	10-16	24.5	14.5	35
CPO 16-35/16-35	20-35	25-35	27	16	38
CPO 50-70/10-16	50-70	10-16	27	20	40
CPO 50-70/10-35	50-70	25-35	30	18.4	40
CPO 50-70/50-70	50-70	50-70	31.8	20	45
CPO 70-150/50-70	70-150	50-70	39	22	60
CPO 70-150/70-150	70-150	70-150	42.6	25	60
CPO 150-240/70-150	150-240	70-150	49.5	30.5	65
CPO 150-240/150-240	150-240	150-240	51.5	30.3	65
